Manual Sampling Rate Setting
SoundLinker™, TV hearMore™, and MoerDuo™ now support manual sampling-rate switching through their onboard controls. Select 24 kHz or 48 kHz directly on the device without connecting the transmitter to a PC.
Choose the right sampling rate for your application
Use 48 kHz for general audio applications where full-range sound quality is preferred. Select 24 kHz when connecting to compatible hearing aids or when optimized hearing-aid performance is required.
Quick Operation Guide
| Product | Required Firmware | Button Operation | LED Indication |
|---|---|---|---|
| SoundLinker™ | V5.2.4 | In Auracast mode, click the Power button once, then press and hold the Power button. | Fast flash ×3: 24 kHz Steady on for 1–2 sec: 48 kHz |
| TV hearMore™ | V5.2.3 | In Auracast mode, press and hold Power + Audio Source for 3 seconds. | Fast flash ×3: 48 kHz Slow flash ×3: 24 kHz |
| MoerDuo™ | V3.7.1 | In Auracast mode, click the Power button once, then press and hold the Power button. | Fast flash ×3: 24 kHz Steady on for 1–2 sec: 48 kHz |
Product Instructions
SoundLinker™
Required firmware: V5.2.4
How to switch
- Enter Auracast mode.
- Click the Power button once.
- Press and hold the Power button.
LED feedback
-
Fast flash ×3:
24 kHz -
Steady on for 1–2 sec:
48 kHz
TV hearMore™
Required firmware: V5.2.3
How to switch
- Enter Auracast mode.
- Press and hold Power + Audio Source for 3 seconds.
LED feedback
-
Fast flash ×3:
48 kHz -
Slow flash ×3:
24 kHz
MoerDuo™
Required firmware: V3.7.1
How to switch
- Enter Auracast mode.
- Click the Power button once.
- Press and hold the Power button.
LED feedback
-
Fast flash ×3:
24 kHz -
Steady on for 1–2 sec:
48 kHz
Update Your Firmware Before Using This Feature
Manual sampling-rate switching requires the firmware version shown above or a later compatible release. Visit the corresponding product page for firmware downloads, update instructions, and important installation notes. For compatible hearing-aid applications, 24 kHz is recommended.
